4-Methyl-N-(2,2,4,4-tetrachloro-5-methyl-3-oxo-8-oxabicyclo[3.2.1.]oct-6-en-1-ylmethyl)-benzenesulfonamide



Holger Meining and Baldur Föhlisch*



Institut f邦r Organische Chemie der Universität Stuttgart,

Pfaffenwaldring 55, D-70569 Stuttgart, Germany
Fax: (+ 49) 711/6854269; e-mail:  baldur.foehlisch@oc.uni-stuttgart.de



Received: 8 March 2004 / Accepted: 17 March 2004 / Published: 1 August 2005



Keywords: cycloaddition, ketones, sulfonamides, heterocycles





A mixture of 1 [1] (2.65 g, 10 mmol) and pentachloroacetone [2] (3.23 g, 14 mmol) was cooled in an ice bath. With magnetic stirring, a 2-molar solution of sodium 2,2,2-trifluoroethoxide in 2,2,2-trifluoroethanol [3] (7 mL, 14 mmol) was added dropwise, over 15 min. Stirring was continued for 15 min at 0 ∼C and then at room temperature for 2每3 hours[4]. The mixture was allowed to stir for a further 2 hours.

The heterogeneous mixture was poured on saturated brine (20 mL). The precipitate was dissolved by adding a little of dichloromethane and water, and the organic layer was separated. The aqueous layer was acidified with hydrochlorid acid to pH 4每5 and then extracted with dichloromethane (4 ´ 20 mL). The combined dichloromethane solutions were washed with satured brine (20 mL) and dried overnight with magnesium sulfate. After filtration, the solution was concentrated in a rotary evaporator. The remaining yellow mass was recrystallized from dry ethanol (60 mL) to yield 4.01 g (87%) of 2 as a colourless crystalline solid.



Melting Point: 177每178 ∼C.



TLC (silica, hexane/tert-butylmethyl ether (1:1 v/v): A light-blue spot emerged after spraying the sheet with vanillin/sulfuric acid reagent followed by heating with a hot-air gun; Rf = 0.31. The starting material (1) showed a red-brown spot at Rf = 0.38.



1H-NMR (250 MHz, CDCl3): 汛= 1.75 (s, 3 H, 5-CH3); 2.45 (s, 3 H, CH3C6H4SO2); ABX sub-spectrum (8 AB-lines, X part as a broad m) with 汛 A = 3.89, 汛 B = 3.58, 汛 X = 4.88, JAB = (-) 13.9 Hz, JAX =10.1 Hz, JBX = 3.3 Hz, 3 H, diastereotopic CH2-NH); 6.34 (s, 2 H, H-7 + H-6); AA*BB* sub-spectrum with 汛 A = 7.76, 汛 B = 7.35, JAB = 8.2 Hz (H-2/6 and H-3/5 from CH3C6H4SO2).



1H-NMR (250 MHz, DMSO-d6): 汛= 1.65 (s, 3 H, 5-CH3); 2.39 (s, 3 H, CH3C6H4SO2); ABX sub-spectrum (8 AB-lines, 4 lines of the X part) with 汛 A = 3.63, 汛 B = 3.44, 汛 X = 8.06, JAB = (-)14.4 Hz, JAX = 7.5 Hz, JBX = 5.7 Hz, 3 H, diastereotopic CH2-NH); 6.46 (d, J = 5.8 Hz, 1 H, H-7); 6.66 (d, J = 5.8 Hz, 1 H, H-6); AA*BB* sub-spectrum with 汛 A = 7.76, 汛 B = 7.36, JAB = 8.0 Hz (H-2/6 and H-3/5 from CH3C6H4SO2).



13C-NMR/DEPT (62.9 MHz, DMSO-d6): 汛=16.2 (+, 5-CH3); 20.9 (+, CH3C6H4SO2); 41.9 (-, CH2-N); 84.7 (Cq, C-4); 87.1 (Cq, C-2); 91.2 (Cq, C-5); 92.7 (Cq, C-1); 126.35 (+, C-2/6 from CH3C6H4SO2-); 129.65 (+, C-3/5 from CH3C6H4SO2); 134.6 (+, C-6); 137.6 (Cq, C-4 from CH3C6H4SO2); 138.0 (+, C-7); 142.85 (Cq, C-1 from CH3C6H4SO2); 185.3 (Cq, C-3).



IR (CHCl3 film, cm-1): 3400 (N-H); 3110, 2960 (C-H); 1773, 1745 (C=O); 1600 (C=C); 1495 (NH); 1340, 1165 cm-1 (SO2).



Elemental Analysis: Calculated for C16H15Cl4NO4S (459.2): C, 41.85%; H, 3.29%; Cl, 30.88%; N, 3.05%; S, 6.98%. Found: C, 41.59%; H, 3.23%; Cl, 30.75%; N, 2.91%; S: 7.03%.



References

1. Meining, H.; Föhlisch, B. Molbank 2005, M408.

2. Bugrova, L. V.; Rudnev, G. K.; Kristich, A. I.; Radchenko, V. I.; Mishchenko, L. F. Zh. Prikl. Khim. (Leningrad) 1973, 46, 1529每1533; J. Appl. Chem. USSR 1973, 2, 1627每1631.

3. a) Föhlisch, B.; Gehrlach, E.; Herter, R. Angew. Chem. 1982, 94, 144; Angew. Chem. Suppl. 1982, 94, 241; Angew. Chem., Int. Ed. Engl. 1982, 21, 137.  b) Sendelbach, S.; Schwetzler-Raschke, R.; Radl, A.; Kaiser, R.; Henle, G. H.; Korfant, H.; Reiner, S.; Föhlisch, B. J. Org. Chem. 1999, 64, 3398每3408.

4. If 1 has not disappeared after that time (check by TLC), more pentachloroacetone (0.7每1.2 g, 3每5 mmol) was added, and the base solution in such amount that a test with wet pH indicator paper showed an alkaline reaction.
