Molbank 2005, M422

http://www.mdpi.net/molbank/



3-(2,5-Dihexyl-4-iodo-phenylethynyl)-[1,10]-phenanthroline



Davood Habibi



Department of Chemistry, Faculty of Sciences, Bu Ali Sina University,

Hamedan, Iran. Code: 6517838683.

e-mail: [email protected]



Received: 13 June 2005 / Accepted: 8 August 2005 / Published: 1 September 2005



Keywords: 1,4-dihexyl-2,5-diiodobenzene, Sonogashira procedure, phenanthroline





The experimental procedure follows a protocol developed by Sonogashira [1]. All reactions were carried out under the atmosphere of dry argon by using standard Schlenk tube techniques.

To a mixture of 3-ethynyl-[1,10]-phenanthroline [2,3] (306 mg, 1.5 mmol) and 1,4-dihexyl-2,5-diiodobenzene (3.735 g, 7.5 mmol) in dry benzene (25 mL), and triethyl amine (10 mL), were added CuI (28.6 mg, 0.15 mmol), and [PdCl2(PPh3)2] (52.6 mg, 0.075 mmol). The reaction mixture was kept at 80oC for 24h while stirring vigorously and monitored with mass spectrometer to see the formation of the desired product. After removal of the solvent, the residue was washed with aqueous potassium cyanide (2%, 30 mL) and distilled water (100 mL), and purified by column chromatography (SiO2, CHCl3) to collect 3-(2,5-dihexyl-4-iodo-phenylethynyl-[1,10]-phenanthroline (215.5 mg, 0.375 mmol, 25%).



Melting Point: > 300¡ãC.



IR (KBr, cm-1): 3205, 2202, 1590, 1477, 1415, 1261, 1202, 1095, 940, 818, 729.



1H-NMR (200 MHz, d6-acetone): ¦Ä= 0.95 (6H, 2CH3); 1.3 (12H, 6CH2); 1.6 (4H, 2CH2); 2.6 (4H, 2CH2); 7.0 (1H, 8'-H); 7.25 (1H, 8-H); 7.4 (2H, 5-H & 5'-H); 7.7 (1H, 6-H); 8.0 (1H, 7-H); 8.2 (1H, 4-H); 8.8 (1H, 9-H); 9.0 (1-H, 2-H).



Elemental Analysis: Calculated for C32H35IN2: C, 66.90%; H, 6.14%; N, 4.88%. Found: C, 67.0%; H, 6.0%; N, 4.70%.



Acknowledgements

The author gratefully acknowledges the financial supports from the Bu Ali Sina University, Hamedan, Iran.



References

1. Sonogashira, K.; Tohda, Y.; Hagihara, N. Tetrahedron Lett. 1975, 4467.

2. Michel, C.; Habibi, D.; Schmittel, M., Molecules, 2001, M224.

3. Michel, C.; Habibi, D.; Schmittel, M., Molecules, 2001, M225.

4. Giesa, R.; Schulz, R. C., Makromol. Chem., 1990, 191, 857.

5. Weder, C.; Wrighton, M. S., Macromolecules, 1996, 29, 5157.

6. Swager, T. M.; Gil, C. J.; Wrighton, M. S., J. Phys. Chem., 1995, 99, 4886.
