Molbank 2007, M551

http://www.mdpi.org/molbank/



Synthesis of Mono- and Dibromo-Derivatives of 1‑Phenylpyrazol‑3‑ol



Eglė Nedzelskytė a, Vytas Martynaitis a, Algirdas Šačkus a, Gernot A. Eller b and Wolfgang Holzer b, *



a Institute of Synthetic Chemistry, Kaunas University of Technology, Radvilėnų pl. 19, LT-50254 Kaunas, Lithuania

b Department of Drug and Natural Product Synthesis, Faculty of Life Sciences, University of Vienna, Althanstrasse 14, A-1090 Vienna, Austria

* Author to whom correspondence should be addressed. Tel: +43-1-4277-55623; E-mail: [email protected]



Received: 30 January 2007 / Accepted: 15 February 2007 / Published: 30 May 2007



Keywords: 1-phenylpyrazol-3-ol, bromination, O-acetylation, NMR spectroscopy



Abstract: Dependent on the reaction conditions, 1-phenylpyrazol-3-ol and bromine give either 4-bromo-1-phenylpyrazol-3-ol (2a) or 4-bromo-1-(4-bromophenyl)pyrazol-3-ol (2b). Treatment of 2a or 2b with refluxing acetic anhydride leads to the corresponding O-acetyl derivatives 3a and 3b, respectively. Detailed spectroscopic data (1H NMR, 13C NMR, 15N NMR, MS, IR) for 2b, 3a and 3b are presented.



In the course of investigations regarding Pd-catalyzed cross coupling reactions with halopyrazoles [1], we prepared 4-bromo-1-phenylpyrazol-3-ol (2a) via reaction of
1-phenylpyrazol-3-ol (1) with one equivalent of bromine in high yield similarly to a previously described procedure [2]. In this respect it seemed interesting for us, if treatment of 1 with an excess of Br2 would lead to a dibromination product (introduction of a bromo atom also into the phenyl ring) and thus to a synthon with two different targets for further C每C bond formation. Such a behaviour was reported in a related case, namely in the bromination of 1-phenylpyrazole, where the use of excess bromine together with severe reaction conditions was found to give 15% 4-bromo-1-(4-bromphenyl)pyrazole besides the main product 4-bromo-1-phenylpyrazole (65%) [3].



Scheme 1



We found that treatment of 1 with 3 equivalents of bromine in a solution of boiling carbon tetrachloride gave the dibromination product 2b in 82% yield (Scheme 1). The structure of 2b was unambiguously determined by spectroscopic methods (1H, 13C, and 15N NMR, MS) and CHN analysis. Furthermore, treatment of 2a and 2b with boiling acetic anhydride afforded the corresponding O-acetyl products 3a and 3b in high yield (Scheme 2).



Scheme 2


4-Bromo-1-(4-bromophenyl)-1H-pyrazol-3-ol (2b)

To a well stirred solution of hydroxypyrazole 1 [4] (1 g, 6.25 mmol) in carbon tetrachloride (30 mL) a solution of bromine (0.32 mL, 6.25 mmol) in carbon tetrachloride (8 mL) was added dropwise during 1 h, and stirring was continued for 2 h at room temperature. Then the reaction temperature was increased to reach reflux temperature within 1 h while adding a second equivalent of bromine (0.32 mL, 6.25 mmol) in carbon tetrachloride (8 mL). After the addition was complete, stirring was continued for further 5 h at reflux temperature. Then another equivalent of bromine (0.32 mL, 6.25 mmol) in carbon tetrachloride (8 mL) was added dropwise during 1 h, and stirring was continued for further 9 h at reflux temperature. The reaction mixture was then allowed to cool to room temperature; the precipitated solid was filtered off, washed with carbon tetrachloride (15 mL), and recrystallized from aqueous ethanol to afford 1.63 g (82%) of pure 2b.



Melting point: 199每201 ∼C, yellowish crystals.



1H NMR (300 MHz, DMSO-d6) [6]: 汛 (ppm) 11.07 (s, 1H, OH), 8.54 (s, 1H, H-5), 7.62 (m, 4H, Ph H-2,3,5,6).



13C NMR (75 MHz, DMSO-d6) [6]: 汛 (ppm) 159.6 (C-3, 3J(C-3,H-5) = 8.8 Hz), 138.5 (Ph C-1), 132.2 (Ph C-3,5), 128.7 (C-5, 1J = 195.0 Hz), 118.6 (Ph C-2,6), 117.3 (Ph C-4), 82.7 (C-4, 2J(C-4,H-5) = 5.0 Hz).



15N NMR (50 MHz, DMSO-d6) [7]: 汛 (ppm) −119.4 (N-2), −189.4 (N-1).



MS (m/z, %) [8]: 320 (M+, 49), 318 (M+, 100), 316 (M+, 45), 239 (22), 237 (21), 157 (23), 157 (23), 155 (19).



Elemental Analysis: Calculated for C9H6Br2N2O (317.96): C, 34.00%; H, 1.90%; N, 8.81%. Found: C, 34.24%; H, 1.95%; N, 8.64%.



4-Bromo-1-phenyl-1H-pyrazol-3-yl acetate (3a)

Bromopyrazole 2a (1.91 g, 8 mmol) 每 which had been prepared by treatment of hydroxypyrazole 1 with one equivalent of bromine at room temperature following a known procedure [2] 每 and excess acetic anhydride (25 mL) were heated to reflux for 30 min. Then, H2O (15 mL) was added and the solution was stirred for further 30 min. The mixture was poured into ice-water (50 mL) and stirred for 30 min. Then the precipitate was filtered off, washed with H2O, and dried to give 2.07 g (92%) of pure 3a.



Melting point: 82每85 ∼C, off-white crystals.



IR (KBr) [5]: 1758 cm−1 (C=O).


1H NMR (300 MHz, CDCl3) [6]: 汛 (ppm) 7.90 (s, 1H, H-5), 7.57 (m, 2H, Ph H-2,6), 7.43 (m, 2H, Ph H-3,5), 7.29 (m, 1H, Ph H-4), 2.38 (s, 3H, CH3).



13C NMR (75 MHz, CDCl3) [6]: 汛 (ppm) 167.6 (CO, 2J(CO,CH3) = 7.1 Hz), 154.0 (C-3, 3J(C-3,H-5) = 9.4 Hz), 139.2 (Ph C-1), 129.5 (Ph C-3,5), 128.4 (C-5, 1J = 194.3 Hz), 127.0 (Ph C-4), 118.5 (Ph C-2,6), 87.7 (C-4, 2J(C-4,H-5) = 5.1 Hz), 20.4 (CH3, 1J = 131.0 Hz).


15N NMR (50 MHz, CDCl3) [7]: 汛 (ppm) −177.0 (N-1); N-2 not found.



MS (m/z, %) [8]: 282 (M+, 6), 280 (M+, 6), 240 (100), 238 (99), 104 (49), 77 (84), 51 (30), 43 (52).



Elemental Analysis: Calculated for C11H9BrN2O2 (281.11): C, 47.00%; H, 3.23%; N, 9.97%. Found: C, 46.74%; H, 3.07%; N, 9.84%.



4-Bromo-1-(4-bromophenyl)-1H-pyrazol-3-yl acetate (3b)

Dibromopyrazole 2b (1.27 g, 4 mmol) and excess acetic anhydride (15 mL) were refluxed for 30 min. Then H2O (10 mL) was added and the solution was stirred for further 30 min. The mixture was poured into ice-water (50 mL) and stirred for 30 min. Then the precipitate was filtered off, washed with H2O, and dried to give 1.17 g (81%) of pure 3b.



Melting point: 77 ∼C, beige powder.



IR (KBr) [5]: 1780, 1761 cm−1 (C=O).



1H NMR (300 MHz, CDCl3) [6]: 汛 (ppm) 7.87 (s, 1H, H-5), 7.55 (m, 2H, Ph H-3,5), 7.46 (m, 2H, Ph H-2,6), 2.38 (s, 3H, CH3).



13C NMR (75 MHz, CDCl3) [6]: 汛 (ppm) 167.5 (CO, 2J(CO,CH3) = 7.1 Hz), 154.4 (C-3, 3J(C-3,H-5) = 9.4 Hz), 138.3 (Ph C-1), 132.6 (Ph C-3,5), 128.3 (C-5, 1J = 194.3 Hz), 120.4 (Ph C-4), 120.0 (Ph C-2,6), 88.4 (C-4, 2J(C-4,H-5) = 5.0 Hz), 20.4 (CH3, 1J = 130.7 Hz).



15N NMR (50 MHz, CDCl3) [7]: 汛 (ppm) −99.2 (N-2), −179.3 (N-1).



MS (m/z, %) [8]: 362 (M+, 1), 360 (M+, 3), 358 (M+, 1), 320 (28), 318 (60), 316 (28), 157 (26), 155 (25), 76 (29), 75 (30), 43 (100).



Elemental Analysis: Calculated for C11H8Br2N2O2 (360.00): C, 36.70%; H, 2.24%; N, 7.78%. Found: C, 36.82%; H, 2.19%; N, 7.76%.



References and Notes


  1. Nedzelskytė, E.; Martynaitis, V.; Šačkus, A.; Eller, G.A.; Holzer, W.; manuscript in preparation.
  2. O'Brien, D.F.; Gates, J.W., Jr. J. Org. Chem. 1966, 31, 1538每1542.
  3. Finar, I.L.; Foster, T. J. Chem. Soc. C 1967, 1494每1497.
  4. Harries, C.; Loth G. Ber. Dtsch. Chem. Ges. 1896, 29, 513每520.
  5. Obtained on a Perkin-Elmer FTIR 1605 spectrophotometer or on a Perkin-Elmer FTIR Spectrum 1000 spectrometer.
  6. Obtained on a Varian UnityPlus 300 spectrometer (299.95 MHz for 1H, 75.43 MHz for 13C) at 28 ∼C. The centre of the solvent signal was used as an internal standard which was related to TMS with 汛 2.49 ppm (1H NMR in DMSO-d6),  汛 7.26 ppm (1H NMR in CDCl3), 汛 39.5 ppm (13C NMR in DMSO-d6), and 汛 77.0 ppm (13C NMR in CDCl3).
  7. Obtained on a Bruker Avance 500 spectrometer (50.68 MHz for 15N) and referenced against neat, external nitromethane (coaxial capillary).
  8. Obtained on a Shimadzu QP 1000 instrument (EI, 70eV).
