Molbank 2006, M460

http://www.mdpi.net/molbank/



2-(cyclohex-2-enyloxy)-isoindole-1,3-dione



Sergiu Coseri



Institute of Macromolecular Chemistry ¡°P.Poni¡± Iasi, Gr.Ghica Voda, 41A, 6600 Iasi, Romania and

National Research Council of Canada, 100 Sussex Dr., Ottawa, ON, K1A 0R6, Canada

e-mail: [email protected]



Received: 30 September 2005 / Accepted: 24 October 2005 / Published: 22 January 2006





A degassed mixture containing 0.245 mmol cyclohexene and 0.05 mmol N-hydroxyphthalimide (NHPI),1,2 in 5 mL acetonitrile was added to a degassed solution of lead tetraacetate3 (0.025 mmol in 5 mL acetonitrile) under nitrogen atmosphere at room temperature. After the completion of the reaction, the solvent and the olefin excess was removed under reduced pressure and the residue was purified by preparative TLC using hexane:ethyl acetate = 2:1 as eluent, giving the above product.



1H-NMR (400 MHz, CDCl3): d= 7.86, 7.77 (Ar, 4 H); 6.10, 5.97 (CH=CH, 2H); 4.77 (O-CH, 1H); 2.17, 2.04, 2.01, 1.85 (CH2, 8H).



13C-NMR (100 MHz, CDCl3): d= 164.7 (C=O); 134.8, 124.3 (Ar); 81.3 (C-O); 77.4 (C=C); 27.7, 24.6, 21.3 (CH2).



References

1. Ishii, Y.; Sakaguchi, S.; Iwahama, T., Adv. Synth. Catal., 2001, 343, 393.

2. Masui, M.; Hosomi, K.; Tsuchida, K.; Ozaki, S., Chem. Pharm. Bull., 1985, 33, 4798.

3. Martin, J.C.; Taylor, J.W.; Drew, E.H., JACS, 1967, 89, 129.



Sample Availability: Available from MDPI.



© 2006 MDPI. All rights reserved.
