Molbank 2006, M472

http://www.mdpi.net/molbank/



1-(ethoxycarbonylmethyl)-3-(1¡¯-tolyl-3¡¯-(ethoxycarbonyl)5¡¯-hydroxypyrazolyl)-2-oxo quinoxaline



Souad Ferfra,Noureddine H.Ahabchane, El Mokhtar Essassi*



Laboratoire de Chimie Organique H¨¦t¨¦rocyclique, Facult¨¦ des Sciences, BP 1014, Avenue Ibn Batouta, Rabat, Maroc

e-mail:  [email protected]

*Author to whom correspondence should be addressed



Received: 13 February 2006 / Accepted: 18 February 2006/ Published: 28 February 2006



Keywords: cyclocondensations, quinoxaline, hydrazonoyl bromide






To a solution of hydrazonoyl bromide (5.70 g, 0.02 mol) 2 and 1 [1]  (3.18 g, 0.01 mol) in tetrahydrofuran (60 ml) was added triethylamine (2.02 g, 0.02 mol in 10 ml of THF). The reaction mixture was refluxed for 48 hours. The solvent was evaporated under reduced pressure and the resulting crude material was chromatographied over silica gel column using 10:90 ethylacetate:hexane as eluent (yield 70%).



Melting point: 182-184¡ãC



IR (KBr , cm-1 ): 1640 ( nN-C=O); 1720 (nN-C=O).



1H- NMR ( 250 MHz, CDCl3): d=  7.81-7.04 (8H, m, H arom); 5.02 (2H, s, NCH2); 4.44 (2H, q, J=7 Hz, CH2); 4.25 (2H, q, J = 7 Hz, CH2);  2.36 (3H, s, CH3-¦µ);  1.37 (3H, t, J = 7 Hz, CH3); 1.27 (3H, t, J = 7 Hz, CH3).



13C- NMR (250MHz, CDCl3): d= 166.5 (Cq); 164.2 (Cq); 161.6 (Cq); 154.5 (Cq); 143.8 (Cq); 143.4 (Cq); 135.9 (Cq); 135.5 (Cq); 129.4 (CHar); 129.1 CHar); 129.1 (Cq); 127.8 (CHar); 126.8 (Cq); 125.3 (CHar); 122.0 (CHar); 120.7 (CHar); 114.0 (CHar); 96 (C4); 62.3 (CH2); 61.7 (CH2); 44.2 (NCH2);  21.0 (¦µ-CH3); 14.2 (CH3).



MS (IE): 476



Reference

1. Ferfra, S. Ahabchane N.H., Essassi, E. M.; Molecules, submitted



Sample Availability: Available from MDPI.



© 2006 MDPI. All rights reserved.
