Molbank 2006, M493

http://www.mdpi.org/molbank/



1-{[Benzyl-(2-cyano-ethyl)-amino]-methyl}-5-methyl-1H-pyrazole-3-carboxylic acid methyl ester



Leila Herrag,1,2*  Rachid Touzani,1,3  Abdelkrim Ramdani1 and Belkheir Hammouti2



1 Laboratoire de Chimie Organique Physique, Département de Chimie , Faculté des Sciences , Université Mohammed Premier , B.P. 524, 60000 Oujda , Maroc.

2Laboratoire de Chimie des Eaux et Corrosion, Département de Chimie, Faculté des  Sciences,  B.P. 717, Oujda, Maroc.

3 Université Mohammed Premier, Faculté Pluridisciplinaire de Nador B.P. 300, 62700 Selouane, Nador, Maroc

E-mail: [email protected]

*Author to whom correspondence should be addressed



Received: 19 July 2006 / Accepted: 31 July 2006 / Published: 1 September 2006



Keywords: pyrazole; propionitrile and tridentate nitrogen donor ligand.



The products of aza-type Michael addition, i.e., β-amino carbonyl compounds and their derivatives, are often used as peptide analogs or precursors of optically active amino acids, amino alcohols, diamines, and lactams [1]. Moreover, β-amino carbonyl functionalities are ubiquitous motifs in natural products such as alkaloids and polyketides [2]. Herein, we report the synthesis of new product using aza-type Michael reactions under mild conditions.





A mixture of 3-(benzylamino)propionitrile 1 [3] (1g; 6.25mmol) and  1-Hydroxymethyl-5-methyl-1H-pyrazole-3-carboxylic acid methyl ester 2 [4] (1.062g ; 6.25 mmol) in 20 ml of acetonitrile was stirred at room temperature for four days, then the mixture was dried with Na2SO4 and filtered.  The solvent was evaporated under reduced pressure. The product 3 has been obtained with a 99% yield as yellow oil.



1H-NMR (300 MHz, CDCl3): δ= 7.31 (CHarom, 5H, s) ; 6.56 ( CHpyr,1H, s) ; 4.94 (OCH3, 3H, s) ; 3.89 ( N-CH2-N, 2H, s) ; 3.75 (C6H5-CH2 ,2H, s) ; 3.01-3.06 (CH2-CH2-CN, 2H,  t, J = 7.33 Hz) ; 2.33-2.37 ( N-CH2 , t, J = 7 Hz) and 2.18 ( CH3, 3H, s).



13C-NMR (CDCl3, 75 MHz): δ= 163.32 (l); 142.91 (i); 141.56 (g); 137.46 (m); 129.154 (n); 129.03; 129.08 (f); 128.26 (o); 118.97 (a); 109.30 (h); 67.82 (e); 56.79 (d); 52.37 (k); 48.36 (c); 17.46 (b); 11.55 (j).



EI-MS (70 eV, m/z): 173 (16); 171; 119 (22); 91 (100).



References:

1. Fustero, S.; Pina, B.; Salavert, E.; Navarro, A.; Ramirez de Arellano, M. C.; Fuentes, A. S. J. Org. Chem. 2002, 67, 4667.

2. Arend, M.; Westermann, B.; Risch, N. Angew. Chem., Int. Ed 1998, 37, 1045.

3. a) Xu, L.W.; Li, L.; Xia, C.-G. Helvetica Chimica Acta, 2004, 87, 1522. b) Azizi, N.; Saidi, M. R.  Tetrahedron, 2004, 60, 383.

4. Touzani, R. ; Ramdani, A. ; El Kadiri, S.; Gourand, F. Molecules, 1999, 4, M116.



© 2006 MDPI. All rights reserved.
